ASTM B338 UNS R56400 seamless tubing supplier in India
Request quotes from multiple suppliers to compare prices of ASTM B338 Gr 5 Titanium Heat Exchanger Tube and WERKSTOFF NR. 3.7165 Bright Annealed Tubing.
Table of content
- Titanium Grade 5 Tube Specification
- Grade 5 titanium seamless tube Types
- UNS R56400 Welded Tubing Chemical Composition
- Titanium Gr 5 High Pressure Tube Mechanical Properties
- Equivalent grade of Ti gr 5 Capillary Tubing
- Titanium Gr 5 High Pressure Tube Physical Properties
- DIN 3.7165 Round Tube Thermal Properties
- Titanium Grade 5 Tubing Price List
- Gr 5 Titanium Bright Annealed Tube Dimension
- Maximum Temperature Limit of Ti Grade 5 Boiler Tube
- Testing of Grade 5 Titanium Tubing
- Annealing and Heat Treatment of UNS R56400 Tubing
| Specification | ASTM B338 / ASME SB338 |
| Surfaces | |
| Standard length | 6 metres |
| Delivery Condition | MF, Bright Annealed, Polished, Annealed and Pickled, Cold Drawn |
| Thickness Range | Schedule 5 to Schedule XXS |
| Manufacturing Type | CEW / Seamless / DOM / ERW / Fabricated / Welded / CDW / CDS / 100% X Ray Welded |
| Surface Finish | BA, 500G, 2B, No.1, No.3, No.8, 800G Mirror finish, 8K, HL, No.4, 2D, Mirror Polished, 1D, 180G, 400G Satin/ Hairline, 320G, 400G, 600G |
| Value Added Services |
|
| END | Plain End, Beveled End, Treaded Tubes |
| Processing Service | Welding, Decoiling, Bending, Punching, Cutting, Moulding |
| Technique | Cold drawn, Cold rolled, Hot rolled, Extrusion Tubes |
| Tolerance |
Titanium Gr 5 High Pressure Tube
UNS R56400 Sanitary Tube
ASTM B338 Gr 5 Titanium Heat Exchanger Tube
WERKSTOFF NR. 3.7165 Bright Annealed Tubing
Grade 5 titanium tubing
Ti Grade 5 High Pressure Tubing
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade 5 | 90 min | 0.1 max | 0.4 max | 0.015 max | 0.05 max | 0.20 max | 5.5-6.75max | 3.5-4.5 |
Ultrasonic testing are used to assess the integrity and any internal defects in the Grade 5 titanium tubing and Ti Grade 5 High Pressure Tubing.
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|
| Titanium Gr. 5 | 950 MPa | 880 MPa | 14 % |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Titanium Grade5 | 3.7165 | R56400 |
Our company holds the forefront as the leading stockist and distributor of high-temperature Cp Grade 5 Titanium Tubing and Ti gr 5 Capillary Tubing.
| Density | Melting point | Poisson’s ratio | Elastic modulus | Shear modulus |
|---|---|---|---|---|
| 4.43 g/cm3 | 1674 °C | 0.31 | 120 GPa | 45 GPa |
Reliable supplier providing competitive rates for high-quality ASTM B338 Grade 5 Ti Exhaust Tubing and Gr 5 Titanium Bright Annealed Tube in India
| Thermal expansion co-efficient | Thermal conductivity |
|---|---|
| 9 µm/m°C | 6.60W/mK |
| Product | Price in USD (Kg) |
Price in Dirham (Kg) |
Price in Euro (Kg) |
|---|---|---|---|
| 10NB OD Titanium Gr 5 Annealed Tube, SCH 40 | US $19.74 | 72.50 AED | € 16.98 |
| 19.05 MM OD X 20 BWG ASME SB 338 GR.5 Tube | US $17.78 | 65.30 AED | € 15.29 |
| Size (Tube OD) | Dimensions | |
|---|---|---|
| Nominal Size in mm, Wall × ID | Gauge | |
| 1 | 0.065 × 0.870 | 16 |
| 1 1/2 | 0.065 × 1.370 | 16 |
| 2 | 0.065 × 1.870 | 16 |
| 2 1/2 | 0.065 × 2.370 | 16 |
| 3 | 0.065 × 2.870 | 16 |
| 4 | 0.065 × 3.870 | 16 |
| 4 | 0.083 × 3.834 | 14 |
| 6 | 0.083 × 4.834 | 14 |
| 6 | 0.083 × 5.834 | 14 |
| 6 | 0.109 × 5.782 | 12 |
| 8 | 0.109 × 7.782 | 12 |
| Maximum Temperature Limit | 800°F (427°C) |
|---|
| Annealing | 732°C |
|---|---|
| Heat Treatment | 904-954°C |
