Reliable Alloy 625 hydraulic ball valves Manufacturer in India
Check Weight Chart of Inconel 600 ball valve
Table of content
- Inconel ball valve specification
- Inconel flanged ball valve chemical composition
- Inconel alloy instrumentation ball valve Mechanical properties
- Equivalent grade of Inconel high pressure ball valve
- Pressure Rating Of Inconel 600 ball valve
- Size Chart of Alloy 625 3 way ball valve
- Types of Inconel ball valve
- ASTM A494 Grade CW6MC ball valve corrosion resistance characteristics
- Pressure & Temperature Limit of Alloy 625 Hydraulic Ball Valves
- Advantages of Inconel N06625 Cryogenic Ball Valves
- Material Testing of Inconel 625 Compression Ball Valves
| Size | 1/4″ to 4″ |
| Standards | ASME B16.34 / API 608 / ISO 17292 |
| Valve Type | 2 Way / 3 Way |
| Pressure Rating | 6000 PSI / 3000 PSI / 10000 PSI / 15000 PSI |
| Bore Type | Full Bore / Reduced Bore |
| End Connections | Socket Weld / Female / Male NPT / Double Ferrule Compression |
| Fire Safe Design | API 607 / ISO 10497 |
| Surface Finish | Machined / Electropolished / Pickled |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
| NPS | PSIG |
|---|---|
| 1/2 – 1-1/2 | 1000 PSIG (69 BARG) |
| 2 | 800 PSIG (55 BARG) |
| 3 | 600 PSIG (41 BARG) |
| 4-5 | 500 PSIG (34 BARG) |
| 6 | 300 PSIG (21 BARG) |
| END CONNECTION SIZE | ORIFICE | A | |||
|---|---|---|---|---|---|
| (IN) | (MM) | (IN) | (MM) | (IN) | (MM) |
| 1/8 | 3.17 | 0.09 | 2.4 | 1.01 | 25.5 |
| 3/16 | 4.76 | 0.13 | 3.2 | 1.1 | 28 |
| 1/4 | 6.35 | 0.19 | 4.8 | 1.2 | 30 |
| 3/8 | 9.52 | 0.28 | 7.1 | 1.45 | 36.5 |
| 1/2 | 12.7 | 0.41 | 10.3 | 1.74 | 44.2 |
| 0.12 | 3 | 0.09 | 2.4 | 1.01 | 25.5 |
| 0.24 | 6 | 0.19 | 4.8 | 1.2 | 30 |
| 0.31 | 8 | 0.19 | 4.8 | 1.23 | 31.2 |
| 0.39 | 10 | 0.28 | 7.1 | 1.45 | 36.5 |
| 0.47 | 12 | 0.41 | 10.3 | 1.74 | 44.2 |
Inconel 625 Hydraulic Ball Valves
Alloy 600 High Pressure Ball Valves
Nickel 601 Cryogenic Ball Valves
UNS N06625 Compression Ball Valves
DIN 2.4816 Instrument Ball Valve
Inconel 718 Flow Control Ball Valves
| Corrosion Type | Performance |
|---|---|
| General Corrosion | Excellent |
| Pitting Corrosion | Very good |
| Crevice Corrosion | Excellent |
| Stress Corrosion Cracking | Very good |
| Seawater Service | Very good |
| Class | Pressure Rating |
|---|---|
| Class 2500 | 6000 psig |
| Class 4500 | 10000 psig |
- Positive Material Identification
- NDT Testing
- Corrosion Test
- Seat Leakage Test
- Hydrostatic Pressure Test
- Dimensional Inspection
- Pneumatic Test
