Are you looking for UNS S31254 seamless tube supplier in India

254 SMO Tubing

Werkstoff Nr. 1.4547 EFW Tube and Alloy 254 High Pressure Tube are commonly used in industries such as aerospace, chemical processing, and marine applications

Table of content

254 SMO Tubing Specification

Specification ASTM A213/ ASME SA213
Surfaces
  • Average roughness value: Ra < 0.8 µm
  • Weld seam area: Ra < 1.6 µm
Standard length 6 metres
Delivery Condition MF, Bright Annealed, Polished, Annealed and Pickled, Cold Drawn
Thickness Range Schedule 5 to Schedule XXS
Manufacturing Type CEW / Seamless / DOM / ERW / Fabricated / Welded / CDW / CDS / 100% X Ray Welded
Surface Finish BA, 500G, 2B, No.1, No.3, No.8, 800G Mirror finish, 8K, HL, No.4, 2D, Mirror Polished, 1D, 180G, 400G Satin/ Hairline, 320G, 400G, 600G
Value Added Services
  • Cutting
  • Destructive and Non Destructive
  • Threading
  • Polishing (Electro & Commercial)
  • Draw & Expansion as per required Size & Length
  • Annealed & Pickled Bending
  • Beveling
  • Ultrasonic Testing
END Plain End, Beveled End, Treaded Tubes
Processing Service Welding, Decoiling, Bending, Punching, Cutting, Moulding
Technique Cold drawn, Cold rolled, Hot rolled, Extrusion Tubes
Tolerance
  • Outer Diameter: +/- 0.2mm
  • Thickness: +/- 10% OR as customer request
  • Length: +/- 10mm

UNS S31254 seamless tube Types

6mo Welded Tubes

6mo Welded Tubes

Werkstoff Nr. 1.4547 EFW Tube

Werkstoff Nr. 1.4547 EFW Tube

Alloy 254 High Pressure Tube

Alloy 254 High Pressure Tube

A213 UNS S31254 Cold Drawn Tube

A213 UNS S31254 Cold Drawn Tube

SMO 254 ERW Tubes

SMO 254 ERW Tubes

SS 254 SMO Tubing

SS 254 SMO Tubing

6mo Welded Tubes Chemical Composition

SMO 254 C Ni Cr Mn Mo Fe Si S Cu P
0.002 maximum 17.05  to  18.05 19.05  to  20.05 1 maximum 6  to  6.05 to 0.08 maximum 0.001 maximum 0.05  to 1 0.003 maximum

The dimensions of A213 UNS S31254 Cold Drawn Tube and SMO 254 ERW Tubes comply with industry standards

Werkstoff Nr. 1.4547 EFW Tube Mechanical Properties

Melting Point Density Tensile Strength Yield Strength (0.2%Offset) Elongation
1320 to 1390 ℃ 8.0 g/cm3 650 300 35 %

Equivalent grade of Alloy 254 High Pressure Tube

STANDARD GOST WERKSTOFF NR. UNS JIS EN AFNOR SIS
SMO 254 – 1.4547 S31254 – X1CrNiMoCuN20-18-7 Z1 CNDU 20.18.06Az 2378
We are the leading stockist and distributor of high-temperature 254 Smo Seamless Tube and 254 SMO Welded Tube.

A213 UNS S31254 Cold Drawn Tube Size Range

Wall Thickness Sizes ( O.D.)
.010 1/16″ , 1/8″ , 3/16″
.020 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″
.012 1/8″
.016 1/8″ , 3/16″
.028 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″
.035 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″
.049 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″
.065 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″
.083 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″
.095 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″
.109 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″
.120 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″
.125 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″
.134 1″
.250 3″
.375 3 1/2″
Find precise ASTM A269 UNS S31254 Capillary Tubing and SMO 254 Coiled Tube dimensions and sizes to meet your specific project demands

SMO 254 ERW Tubes Dimension

OD inches Ave. Wall inches D/t Ratio ID inches Tube Cross Sectional Area (in2) Internal Area (in2)
0.250 0.020 12.50 0.210 0.0145 0.0346
0.250 0.028 8.93 0.194 0.0195 0.0296
0.250 0.035 7.14 0.180 0.0236 0.0254
0.250 0.049 5.10 0.152 0.0309 0.0181
0.250 0.065 3.85 0.120 0.0378 0.0113
0.375 0.020 18.75 0.335 0.0223 0.0881
0.375 0.028 13.39 0.319 0.0305 0.0799
0.375 0.035 10.71 0.305 0.0374 0.0731
0.375 0.049 7.65 0.277 0.0502 0.0603
0.375 0.065 5.77 0.245 0.0633 0.0471
0.500 0.020 25.00 0.460 0.0302 0.1662
0.500 0.028 17.86 0.444 0.0415 0.1548
0.500 0.035 14.29 0.430 0.0511 0.1452
0.500 0.049 10.20 0.402 0.0694 0.1213
0.500 0.065 7.69 0.370 0.0888 0.1075
0.500 0.083 6.02 0.334 0.1087 0.0876
0.625 0.020 31.25 0.585 0.0380 0.2688
0.625 0.028 22.32 0.569 0.0525 0.2543
0.625 0.035 17.86 0.555 0.0649 0.2419
0.625 0.049 12.76 0.527 0.0887 0.2181
0.625 0.065 9.62 0.495 0.1144 0.1924
0.625 0.083 7.53 0.459 0.1413 0.1655
0.625 0.095 6.58 0.435 0.1582 0.1486
0.625 0.109 5.73 0.407 0.1767 0.1301
0.750 0.028 26.79 0.694 0.0635 0.3783
0.750 0.035 21.43 0.680 0.0786 0.3632
0.750 0.049 15.31 0.652 0.1079 0.3339
0.750 0.065 11.54 0.620 0.1399 0.3019
0.750 0.083 9.04 0.584 0.1739 0.2679
0.750 0.095 7.89 0.560 0.1955 0.2463
0.750 0.109 6.88 0.532 0.2195 0.2223
0.750 0.120 6.25 0.510 0.2375 0.2043
0.875 0.020 43.75 0.835 0.0537 0.5476
0.875 0.028 31.25 0.819 0.0745 0.5268
0.875 0.035 25.00 0.805 0.0924 0.5090
0.875 0.049 17.86 0.777 0.1272 0.4742
0.875 0.065 13.46 0.745 0.1654 0.4359
0.875 0.083 10.54 0.709 0.2065 0.3948
0.875 0.095 9.21 0.685 0.2328 0.3685
0.875 0.109 8.03 0.657 0.2623 0.3390
0.875 0.120 7.29 0.635 0.2846 0.316L7
1.000 0.028 35.71 0.944 0.0855 0.6999
1.000 0.035 28.57 0.930 0.1061 0.6793
1.000 0.049 20.41 0.902 0.1464 0.6390
1.000 0.065 15.38 0.870 0.1909 0.5945
1.000 0.083 12.05 0.834 0.2391 0.5463
1.000 0.095 10.53 0.810 0.2701 0.5153
1.000 0.109 9.17 0.782 0.3051 0.4803
1.000 0.120 8.33 0.760 0.3318 0.4536
1.000 0.134 7.46 0.732 0.3646 0.4208
1.250 0.035 35.71 1.180 0.1336 1.0936
1.250 0.049 25.51 1.152 0.1849 1.0423
1.250 0.065 19.23 1.120 0.2420 0.9852
1.250 0.083 15.06 1.084 0.316L3 0.9229
1.250 0.095 13.16 1.060 0.3447 0.8825
1.250 0.109 11.47 1.032 0.3907 0.8365
1.250 0.120 10.42 1.010 0.4260 0.8012
1.250 0.134 9.33 0.982 0.4698 0.7574
1.500 0.035 42.86 1.430 0.1611 1.6061
1.500 0.049 30.61 1.402 0.2234 1.5438
1.500 0.065 23.08 1.370 0.2930 1.4741
1.500 0.083 18.07 1.334 0.3695 1.3977
1.500 0.095 15.79 1.310 0.4193 1.3478
1.500 0.109 13.76 1.282 0.4763 1.2908
1.500 0.120 12.50 1.260 0.5202 1.2469
1.500 0.134 11.19 1.232 0.5750 1.1921
1.500 0.148 10.14 1.204 0.6286 1.1385
1.750 0.035 50.00 1.680 0.1886 2.2167
1.750 0.049 40.82 1.902 0.3003 2.8413
1.750 0.065 26.92 1.620 0.3441 2.0612
1.750 0.083 21.08 1.584 0.4347 1.9706
1.750 0.095 18.42 1.560 0.4939 1.9113
1.750 0.109 16.06 1.532 0.5619 1.8433
1.750 0.120 14.58 1.510 0.6145 1.7908
1.750 0.134 13.06 1.482 0.6803 1.7250
1.750 0.148 11.82 1.454 0.7449 1.6604
1.750 0.165 10.61 1.420 0.8216 1.5837
2.000 0.035 57.14 1.930 0.2161 2.9255
2.000 0.049 40.82 1.902 0.3003 2.8413
2.000 0.065 30.77 1.870 0.3951 2.7465
2.000 0.083 24.10 1.834 0.4999 2.6417
2.000 0.095 21.05 1.810 0.5685 2.5730
2.000 0.109 18.35 1.782 0.6475 2.4941
2.000 0.120 16.67 1.760 0.7087 2.4328
2.000 0.134 14.93 1.732 0.7855 2.3561
2.000 0.148 13.51 1.704 0.8611 2.2805
2.000 0.165 12.12 1.670 0.9512 2.1904

Application of SMO 254 Coiled Tube

  • Chemical processing
  • Food processing equipment
  • Beverage industry
  • Petrochemical industry
  • Pharmaceutical equipment
